MEAN WELL TDR-240-24 24V 10A 240W Slim with LED PFC Function

Description

• Three-Phase 340~550VAC wide range input (Dual phase operation possible)
• Protections: Short circuit / Overload / Over voltage / Over temperature
• Cooling by free air convection
• Built-in constant current limiting circuit
• 3 years warranty

Features
Three-Phase 340~550VAC wide range input (Dual phase operation possible)
63mm slim width
Built-in passive PFC function compliance to EN61000-3-2
High efficiency 92% and low power dissipation
Protections: Short circuit / Overload / Over voltage / Over temperature
Cooling by free air convection
Full power between -30~+60
Built-in constant current limiting circuit
Can be installed on DIN rail TS-35/7.5 or 15
UL61010(industrial control control equipment)approved
EN61000-6-2(EN50082-2) industrial immunity level
DC OK relay contact
3 years warranty
Applications
Industrial control system
Semiconductor fabrication equipment
Factory automation
Electro-mechanical apparatus
